LOADING AND PACKING SYSTEM
TRAY FORMER & LOADER
- Erection of precreased Cardboard Sheet
- Folding of sheet into tray form with gluing
- Automatic Collation
- Feeding of collated product into Tray
- Final Folding of Tray
| Output - | 22 Trays / Min – Max. |
| Tray Size - | 140 x 240 x 40 – Min. 300 x 400 x 100 – Max. |
| Glue Type - | Hot Melt |
| Power requirement - | 6 KW |
| Air consumed - | 15 m3 / hr at 6 bar |
| Machine dimensions - (including collating system) |
3000 length x 2260 width x 1700 height |
| Net Weight - | Appx. 1,100 Kg |
The above specification is subject to change without prior notice
Please contact us for more details
